Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-1
4-4
(4) Periodic maintenance Procedures
CH:Check / CL:Clean / AD:Adjust / LU:Lubrication / RE:Replace
Parts name Parts No. PM maintenance (x1000 counts) Remark
Set UP User Call 100 Please do not use spray containing flamable gas for air-blow or air-brush purposes.
1 IMAGE QUALITY --- CH CH CH
AD AD AD
2 MK-1150
MK-1151
MK-1152
MK-1154
1702RV0NL0
1702RV0JP0
1702RV0US0
1702RV0AS0
RE Drum unit, Developer unit
3 INSIDE OF MACHINE --- CL CL Vacuum: In particular, remove toner and paper dust around imaging and conveying section.
4 PULLEY PICKUP ASSY
PULLEY FEED ASSY
302HN06080
302F906230
CL CL Alcohol or dry cloth if no replacement.
5 ROLLER M/P ASSY 302HS08260 CL CL Alcohol or dry cloth if no replacement.

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
