2RV/2RW/2RX/2RY/3RA
9-1
9 Appendixes
9-1 Appendixes
(1) Repetitive defects gauge
*: The repetitive marks interval may vary depending on operating conditions.
First occurrence of defect
93.1mm / 3 11/16” Fuser belt/Press roller
94.2 mm / 3 3/4” Drum
43.9 mm / 1 3/4” Sleeve roller
47.8 mm / 1 7/8” Transfer roller
