Description of event log
No. Items Contents
(1) System version
(2) System date
(3) Engine firmware version
(4) Engine boot version
(5) Operation panel firmware version
(6) Machine serial number
(7) Life counter
(8) Paper Jam
Log
# Count. Event
Remembers 1 to 16 of
occurrence.
If the past paper jam
occurrence is less than 16,
all of them are indicated.
The oldest log is deleted
when exceeding 16
events.
The total page count at the
time of a paper jam.
Log code ( 5 types in hexa-
decimal)
(a) Cause of paper jam
(b) Paper source
(c) Paper size
(d) Paper type
(e) Paper eject
(a)Detail of Cause of paper jam (Hexadecimal)
*Refer to [7-1 (3) Terms of paper jam detection] for the cause details of paper jam.
(See page 7-30)
(b) Detail of paper source (Hexadecimal)
00: MP tray
01: Cassette 1
02: Cassette 2 (paper feeder)
03: Cassette 3 (paper feeder)
04 to 09: Reserved
(c) Detail of paper size (Hexadecimal)
00: Not specified
01: Monarch
02: Business
03: International DL
04: International C5
05: Executive
06: Letter-R
86: Letter-E
07: Legal
08: A4R
88: A4E
09: B5R
89: B5E
0A: A3
0B: B4
0C: Ledger
0D: A5R
0E: A6
0F: B6
10: Commercial #9
11: Commercial #6
12: ISO B5
13: Custom size
1E: C4
1F: Hagaki
20: Oufuku Hagaki
21: Oficio II
22: Special 1
23: Special 2
24: A3 Wide
25: Ledger Wide
26: Full bleed paper
(12 x 8)
27: 8K
28: 16K-R
A8: 16K-E
32: Statement-R
B2: Statement-E
33: Folio
34: Youkei type 2
35: Youkei type 4

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
