Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-33
J0509 No paper feed from the MP
tray
Condition: Paper is damaged (Paper is caught
up, the paper conveying force is lowered or paper
slips).
J0509 No paper feed from the MP
tray
Condition: Paper is not damaged (The MP bottom
plate does not ascend or feed drive does not
start).
J0511 Multi feed jam
J0512/J0513 Multi feed jam
J0518 Multi-feeding from the duplex
section
J0519 Multi-feeding from the MP
tray
J1403 PF feed sensor non-arrival
jam
Target: Paper feeder 2
Condition: Paper is not damaged (Paper feed
does not start or the PF conveying clutch does
not operate properly).
J1403 PF feed sensor non-arrival
jam
Target: Paper feeder 2
Condition: Paper is damaged (Paper is caught
up, the paper conveying force is lowered or paper
slips).
J1413 PF feed sensor stay jam Target: Paper feeder 2
J4002/J4003 Registration sensor non-
arrival jam
Condition: Paper is damaged.
J4002/J4003 Registration sensor non-
arrival jam
Condition: Paper is not damaged. (The PF con-
veying roller does not rotate properly. The PF
conveying clutch does not operate properly.)
J4008 Registration sensor non-
arrival jam
J4012/J4013/J4018 Registration sensor stay jam
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper jam before the fuser section
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper jam in the fuser section
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper rolled up on the fuser roller
(leading edge margin less than 4.0mm)
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper rolled up on the fuser roller
(leading edge margin 4.0mm or more)
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper jam after passing the lower exit
roller
J4211/J4212/J4213/
J4218/J4219
Exit sensor stay jam Condition: Paper jam in the fuser section
J4211/J4212/J4213/
J4218/J4219
Exit sensor stay jam Condition: Paper jam in the exit unit
J4211/J4212/J4213/
J4218/J4219
Exit sensor stay jam Condition: Paper jam at FD guide
Error code Contents note

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
