2RV/2RW/2RX/2RY/3RA-3
7-67
2 Checking the paper foreign objects are on the
paper.
Remove the paper with for-
eign objects.
3 Checking the paper The paper leading edge is
bent.
Remove the bent paper.
4 Checking the paper The paper is wavy. Correct or replace paper. If
difficult to replace, re-load
paper by switching top and
bottom ends or turning it over.
5 (In case paper hits the FD
guide and jams) Cleaning
the FD guide
Toner is fused on the FD
guide.
Clean the conveying side of
the FD guide.
6 (In case paper jam occurs
at the FD guide) Replacing
paper
The paper curls. Replace with long grain
paper.
7 (In case paper jam occurs
at the FD guide) Replacing
paper
Paper stiffness is lowered
with moisture.
Replace the paper.
8 (In case paper jam occurs
at the FD guide) Checking
paper
The actual paper and the
paper settings (media
type, paper size) do not
match.
Select the proper media type
in the system menu.
9 (In case paper hits the FD
guide and jams) Checking
the conveying path
Paper is caught up at the
FD guide or paper piece.
If there is a paper piece or
foreign object on the convey-
ing side or a burr on the con-
veying side of the FD guide
or on the parts such as actua-
tor, remove it. If not repaired,
replace it.
10 (In case paper hits the FD
guide and jams) Checking
the FD guide
The FD guide does not
operate properly.
Reattach the FD guide and
reconnect the exit unit con-
nector.
11 (In case paper hits the FD
guide and jams) Checking
connection
The connector is not prop-
erly connected or the wire
is faulty.
Clean the terminal of the fol-
lowing wire connectors and
reconnect the connectors. If
there is no continuity, replace
the wire.
• Exit solenoid - Main/engine
PWB (YC1)
12 (In case paper hits the FD
guide and jams) Checking
the exit solenoid
The exit solenoid does not
operate properly.
Reattach the exit solenoid
and reconnect the connector.
If not repaired, replace it.
13 (In case paper hits the FD
guide and jams) Replac-
ing the main/engine PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
