Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
8-6
YC507
LCD
model
1 +5V2 - 5 V DC 5 V DC power
2 BUZZER I 0/5 V DC(pulse) buzzer
3 KEY1 I 0/3.3 V DC KEY1 signal
4 LED6 I 0/3.3 V DC LED6 cathode
5 KEY2 I 0/3.3 V DC KEY2 signal:
6 +3.3V2 - 3.3 V DC 3.3 V DC power supply
7 LED8 I 0/3.3 V DC LED8 cathode
8 GND - 0 V DC Ground
9 LED5 I 0/3.3 V DC LED5 cathode
10 KEY3 I 0/3.3 V DC KEY3 signal
11 LED4 I 0/3.3 V DC LED4 cathode
12 KEY0 I 0/3.3 V DC KEY0 signal
13 LED0 I 0/3.3 V DC LED0 cathode
14 LED7 I 0/3.3 V DC LED7 cathode
15 LED1 I 0/3.3 V DC LED1 cathode
16 LED3 I 0/3.3 V DC LED3 cathode
17 LED2 I 0/3.3 V DC LED2 cathode
YC507 1 +5V2 - 5 V DC 5 V DC power
LED
model
2 P2CSDAT I 0/3.3 V DC Panel communication data sending sig-
nal
3 P2CWAKEUP I 0/3.3 V DC Panel recovery notification signal
4 C2PSDAT O 0/3.3 V DC Panel communication data receiving sig-
nal
5 ESAVERKEY I 0/3.3 V DC ESAVERKEY detection signal
6 +3.3V2 - 3.3 V DC 3.3 V DC power supply
7 C2PRSTN O 0/3.3 V DC Panel reset signal
8 GND - 0 V DC Ground
YC510 1 GND - 0 V DC Ground
2 DATAP I/O LVDS USB data signal
3 DATAN I/O LVDS USB data signal
4 VBUS(+5.0V4) - 5 V DC 5 V DC power
5 FGND - 0 V DC Ground
Connec-
tor
Pin Signal I/O Voltage Description

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
