Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
8-10
Connector access point
YC101: Inlet
YC102: Fuser heater, thermal cut-off
YC103: Main/Engine PWB
Connec-
tor
Pin Signal I/O Voltage Description
YC101 1 L - AC power voltage Commercial power connection
2 N - AC power voltage Commercial power connection
YC102 1 HEATERCOM - AC power voltage Heater live side
2 HEATERLIVE - AC power voltage Heater neutral side
YC103 1 RELAY I 0/3.3 V DC Relay control signal
2 STANDBYN I 0/3.3 V DC Sleep control signal
3 HEAT I 0/3.3 V DC Heater lighting signal
4 ZCROSS O 0/3.3 V DC Zero cross signal
5 GND - 0 V DC Ground
6 GND - 0 V DC Ground
7 GND - 0 V DC Ground
8 +24V0 - 8/24 V DC 24 V DC power (8V in off-mode)
9 +24V0 - 8/24 V DC 24 V DC power (8V in off-mode)
10 +24V0 - 8/24 V DC 24 V DC power (8V in off-mode)

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
