Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
8-14
Connector access point
YC1: Main/Engine PWB
Connec-
tor
Pin Signal I/O Voltage Description
YC1 1 LED2 O 0/3.3 V DC LED2 cathode
2 LED3 O 0/3.3 V DC LED3 cathode
3 LED1 O 0/3.3 V DC LED1 cathode
4 LED7 O 0/3.3 V DC LED7 cathode
5 LED0 O 0/3.3 V DC LED0 cathode
6 KEY0 O 0/3.3 V DC KEY0 signal
7 LED4 O 0/3.3 V DC LED4 cathode
8 KEY3 O 0/3.3 V DC KEY3 signal
9 LED5 O 0/3.3 V DC LED5 cathode
10 GND - 0 V DC Ground
11 LED8 O 0/3.3 V DC LED8 cathode
12 +3.3V2 - 3.3 V DC 3.3 V DC power supply
13 KEY2 O 0/3.3 V DC KEY2 signal
14 LED6 O 0/3.3 V DC LED6 cathode
15 KEY1 O 0/3.3 V DC KEY1 signal
16 BUZZER O 0/5 V DC(pulse) buzzer
17 +5V2 - 5 V DC 5 V DC power

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
