Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-1
3-9
Part name table
*1:Wi-Fi model only, *2:LCD model only, *3:LED model only
No. Name used in service manual Name used in parts list Part. No.
2
Main/Engine PWB
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
PARTS PWB MAIN ENGINE ASSY SP
PARTS PWB MAIN ENGINE ASSY EU SP
302RV94080
302RV94090
302RW94010
302RW94020
302RX94010
302RX94020
302RY94010
302RY94020
3 Wi-Fi PWB *1 PARTS WiFi UNIT SP 302R794010
4
Power source PWB
PARTS UNIT LOW VOLTAGE 100V SP
PARTS UNIT LOW VOLTAGE 230V SP
302RV94210
302RV94220
5 Eraser PWB PARTS PWB ERASER ASSY SP 302RV94110
6 USB PWB PARTS PWB FRONT PWB ASSY SP 302RV94120
7
High-voltage PWB
PARTS UNIT HIGH VOLTAGE SP
PARTS UNIT HIGH VOLTAGE J SP
302RV94190
302RV94200
9 Operation panel PWB *2 PARTS PWB P PANEL ASSY SP 302RX94030
11 Grid PWB (DK-1150) (302RV93010)
12 APC PWB (LK-1150) (302RV93070)
13 Operation panel PWB *3 PARTS PWB L PANEL ASSY SP 302RV94100
14 PF main PWB PARTS PWB PF CONT ASSY SP 303RA94010

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
