Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
3-12
Part name table
No. Name used in service manual Name used in parts list Part. No.
1 Power switch PARTS PWB SWITCH ASSY SP 302RV94130
2 Paper sensor PARTS SENSOR OPT. SP 302P794010
3
Registration sensor
PARTS UNIT HIGH VOLTAGE SP
PARTS UNIT HIGH VOLTAGE J SP
302RV94190
302RV94200
4
Toner sensor
PARTS PWB ASSY EMPTY SENSOR
SP
302RV94170
5 MP paper sensor PARTS SENSOR OPT. SP 302P794010
6 Temp/Humid sensor P.W.BOARD ASSY THERMISTOR 3V2M201100
7 Interlock switch SW.MICRO 7SM010104+++H01
8 Thermopile PARTS THERMOPILE ASSY SP 302RH94110
9 In-machine temperature sensor PARTS PWB THERMISTOR ASSY SP 302RV94150
10 Waste toner sensor PARTS PWB ASSY FULL SENSOR SP 302RV94140
11 Eject sensor
(FK-1150)
(FK-1152)
(FK-1151)
(302RV93050)
(302RV93060)
(302RY93020)
12 Fuser pressure release sensor
13 Fuser edge thermistor
14 Rotation detecting sensor
15 PF paper sensor PARTS PWB PF CONT ASSY SP 303RA94010
16 PF feed sensor PARTS SENSOR OPT. SP 302P794010

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
