Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
3-16
1. Developer clutch .................................. Controlling the drive to developer unit.
2. Registration clutch ............................... Registration roller drive control
3. Paper feed clutch ................................. Controlling the drive of cassette paper feed
4. MP solenoid ......................................... Controlling the drive of MP lift guide
5. Eject solenoid ....................................... Switching the reverse guide
6. Fuser heater ......................................... Heating the fuser belt
7. Thermal cut (center) ............................. Shutting off the fuser heater power supply when the heat roller is
abnormally high (edge).
8. Thermal cut (edge) ............................... Shutting off the fuser heater power supply when the heat roller is
abnormally high (edge).
9. PF paper feed clutch ............................ Controlling the drive of PF cassette paper feed
10. PF feed clutch ...................................... Controlling the conveying drive of PF paper
Part name table
No. Name used in service manual Name used in parts list Part. No.
1 Developer clutch PARTS CLUTCH 35 Z35R SP 302NR94010
2 Registration clutch PARTS CLUTCH 35 Z35R SP 302NR94010
3 Paper feed clutch PARTS CLUTCH 35 Z35R SP 302NR94010
4 MP solenoid SOLENOID MPF 302HN44160
5 Eject solenoid SOLENOID FD ASSY SP 302HN94140
6 Fuser heater
(FK-1150)
(FK-1152)
(FK-1151)
(302RV93050)
(302RV93060)
(302RY93020)
7 Thermal cut (center)
8 Thermal cut (edge)
9 PF paper feed clutch PARTS CLUTCH 35 Z35R SP 302NR94010
10 PF feed roller PARTS CLUTCH 35 Z35R SP 302NR94010

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
