Installing Option Units
A-19
12
If the duplexer is installed, secure the power cord to the duplexer.
Take care not to loosen the power cord.
13
If the duplexer is installed, remove the two cut-out portions from the
upper part of the duplexer rear cover removed in step 5.
14
Reinstall the duplexer rear cover.
NO
Duplexer
Rear Cover
To Next Page
