EDS-MD® Medical Device Server User Guide 106
Appendix D: Lantronix Power Cords, Cables, Adapters
and Serial Port Pinouts
Lantronix cables and adapters for use with EDS-MD 4, EDS-MD 8 and EDS-MD 16 medical device
servers are listed here according to part number and application.
Cables and Adapters
Table D-1 Lantronix Cables and Adapters
Lantronix P/N Description Applications
500-103-R RJ45-to DB9F Connects the RJ45 RS232 serial ports of EDS-MD to a DB9M DTE
interface of a PC or serial device to check that serial ports in the EDS-
MD are functioning properly.
200.2066A Adapter RJ45-to-
DB25M
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
RJ45 serial ports to the DB25F DTE interface of a serial device.
200.2067A Adapter RJ45-to-
DB25F
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
RJ45 serial ports to the DB25M DTE interface of a serial device.
200.2069A Adapter RJ45-to-
DB9M
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
RJ45 serial ports to the DB9F DTE interface of a serial device.
200.2070A Adapter RJ45-to-
DB9F
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
to the DB9M DTE interface of a PC or serial device.
200.2071 Adapter RJ45-to-
DB9M
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
RJ45 serial ports to the DB9F DCE interface of a serial device.
200.2072 Adapter RJ45-to-
DB9F
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
to the DB9M DCE interface of a PC or serial device.
200.2073 Adapter RJ45-to-
DB25M
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
RJ45 serial ports to the DB25F DCE interface of a serial device.
200.2074 Adapter RJ45-to-
DB25F
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
RJ45 serial ports to the DB25M DCE interface of a serial device.
930-073-R Power Cord,
Hospital Grade, US
Connects the EDS-MD to an AC power outlet, for the United States.
930-074-R Power Cord,
Hospital Grade, EU
Connects the EDS-MD to an AC power outlet, for Europe.
930-075-R Power Cord,
Hospital Grade, UK
Connects the EDS-MD to an AC power outlet, for the United Kingdom.
930-076-R Power Cord,
Hospital Grade,
Australia
Connects the EDS-MD to an AC power outlet, for Australia.
930-077-R Power Cord,
Hospital Grade,
Israel
Connects the EDS-MD to an AC power outlet, for Israel.
ADP010104-01 Adapter "Rolled"
RJ45-to-RJ45
Allows a standard straight-pinned CAT5 cable to connect the EDS-MD
to an RJ45 console port on products from Cisco and other
manufacturers.
