Lantronix EDS-MD Series User Manual

3: Installation of EDS-MD Device Servers
EDS-MD® Medical Device Server User Guide 25
To restore factory default settings:
1. Power cycle the unit.
2. During the bootup, hold down the reset-to-default button for a minimum of 25 seconds.
3. Release the button. The firmware restores factory default settings to the configuration.
Technical Specification
Category Description
NETWORK INTERFACE
Ethernet Ports 3 RJ45 10Base-T/100Base-TX/1000Base-T Ethernet ports
Auto sensing
Automatic MDI/MDI-X crossover
Full duplex IEEE 802.3x flow control
Half-duplex back pressure flow control
Left LED Indicator See Table 3-7.
Right LED Indicator See Table 3-7.
Isolation from internal circuit 1.5 KVAC
Isolation from adjacent port 1.5 KVAC
USB INTERFACE
USB Ports 2 of USB-A Host, USB 2.0, Full Speed only
Output Capability 0.5 A
Isolation from internal circuit 1.5 KVAC
Isolation from adjacent port 1.5 KVAC
SERIAL INTERFACE
Serial Ports Options of 4-port, 8-port, 16-port
RS232 Serial Ports DTE via RJ45 connectors
Baud rate Selectable from 300 bps to 921600 bps
Serial Line Formats Characters: 7 or 8 data bits
Stop bits: 1 or 2
Parity: odd, even, none
Modem Control DTR/DSR
Flow Control Hardware: CTS/RTS
Software: XON/XOFF
Serial LED Indicators See Table 3-6.
Protection from ESD 15kV (human body model)
Isolation from internal circuit 1.5 KVAC
Isolation from adjacent port 1.5 KVAC
Reset-to-Default-Parameters Switch Side panel pin-hole recessed push button switch

Lantronix EDS-MD Series Specifications

General

Brand	Lantronix
Model	EDS-MD Series
Category	Server
Language	English
