3: Installation of EDS-MD Device Servers
EDS-MD® Medical Device Server User Guide 26
Category (continued) Description
POWER RATING
Power Input AC Connector IEC60320 C14 receptacle with no power switch
Power Usage 100-240 VAC, 50/60 Hz, 0.4A, 23W maximum
PHYSICALS
Dimensions L x W x H = 8.25 x 7.5 x 2.4 in. (21 x 19 x 6 cm)
Weight 16-port = 2.0 lbs (0.9 Kg)
8-port = 1.8 lbs (0.82 Kg)
4-port = 1.75 lbs (0.8 Kg)
Environmental Temperature Operating 0° to 50°C (32° to 122°F)
Temperature for Transportation and Storage -30° to 80°C
Humidity 0% to 95% non-condensing
Atmospheric Pressure 50 kPa to 105 kPa
Humidity Operating 20% to 90% relative humidity, non-condensing
