EDS-MD® Medical Device Server User Guide 38
6: Network Settings
The Network Settings show the status of the EDS-MD device interface/link and lets you configure
the settings on the device. Interface settings are related to the configuration of the IP and related
protocols. Link settings are related to the physical link connection, which carries the IP traffic.
The EDS-MD device server contains three interfaces:.
Network 1 Interface (eth0) or Link (eth0)
Network 2 Interface (eth1) or Link (eth1)
Network 3 Interface (eth2) or Link (eth2)
Notes:.
Some settings require a reboot to take effect. These settings are noted below.
Wait a minimum of 10-20 seconds after rebooting the unit before attempting to make
any subsequent connections.
The blue text in the XML command strings of this chapter are to be replaced with a
user-specified name.
Network 1 (eth0) Status
In the Network 1 status pages, you can view both the current interface operational settings as well
as the settings that would take effect upon a device reboot, as well as Link, QoS and Failover
status information.
To view Ethernet (eth0) Interface status, click Network on the menu and select Network 1 ->
Interface -> Status.
To view Ethernet (eth0) Link status, click Network on the menu and select Network 1 -> Link
-> Status.
To view Ethernet (eth0) QoS status, click Network on the menu and select Network 1 -> QoS
-> Status.
To view Ethernet (eth0) Failover status, click Network on the menu and select Network 1 ->
Failover -> Status.
Network 1 (eth0) Interface Settings
Table 6-1 shows the network interface settings that can be configured.
Table 6-1 Network 1 (eth0) Interface Settings
Network 1 (eth0)
Interface Settings
Description
State Select to enable or disable the interface.
