EDS-MD® Medical Device Server User Guide 95

13: Updating Firmware

Obtaining Firmware

Obtain the most up-to-date firmware and release notes for the unit from the Lantronix Web site

(www.lantronix.com/support/downloads/

) or by using anonymous FTP (ftp://ftp.lantronix.com/).

Loading New Firmware through Web Manager

Upload the firmware using the device web manager System page.

To upload new firmware:

1. Select System in the menu bar. The System page appears.

Figure 13-1 Uploading New Firmware

2. Click Browse (under the Upload New Firmware heading) to browse to the firmware file.

3. Select the file and click Open.

4. Click Upload to install the firmware on the EDS-MD unit.
