Lantronix EDS-MD Series User Manual

4: Using DeviceInstaller
EDS-MD® Medical Device Server User Guide 31
Device Detail Summary
Note: The settings are Display Only in this table unless otherwise noted
Current Settings Description
Name Shows “EDS-MD”.
DHCP Device Name
Displays one of the names the EDS-MD device will send to the DHCP
server if it is configured to obtain an address in this manner.
Group
Configurable field. Enter a group to categorize the EDS-MD unit. Double-
click the field, type in the value, and press Enter to complete. This group
name is local to this PC and is not visible on other PCs or laptops using
DeviceInstaller.
Comments
Configurable field. Enter comments for the EDS-MD device. Double-click
the field, type in the value, and press Enter to complete. This description or
comment is local to this PC and is not visible on other PCs or laptops using
DeviceInstaller.
Device Family Shows the EDS device family type as “”EDS-MD“.
Short Name Shows “”edsmd4”, ”edsmd8”, or ”edsmd16” by default.
Long Name Shows “Lantronix EDS-MD4”, ”Lantronix EDS-MD”, or ”Lantronix EDS-
MD16” by default.
Type Shows the device type as “EDS-MD”.
ID Shows the EDS-MD ID embedded within the unit.
Hardware Address Shows the EDS-MD hardware (MAC) address.
Firmware Version Shows the firmware currently installed on the EDS-MD.
Extended Firmware Version Provides additional information on the firmware version.
Online Status Shows the EDS-MD status as Online, Offline, Unreachable (the EDS-MD
device is on a different subnet), or Busy (the EDS-MD is currently
performing a task).
IP Address Shows the EDS-MD current IP address. To change the IP address, click the
Assign IP button on the DeviceInstaller menu bar.
IP Address was Obtained Appears “Dynamically” if the EDS-MD unit automatically received an IP
address (e.g., from DHCP). Appears “Statically” if the IP address was
configured manually.
If the IP address was assigned dynamically, the following fields appear:
 Obtain via DHCP with values of True or False.
 Obtain via BOOTP with values of True or False.
Subnet Mask Shows the subnet mask specifying the network segment on which the EDS-
MD device resides.
Gateway Shows the IP address of the router of this network. There is no default.
Number of Ports Shows the number of serial ports on this EDS-MD device server.
Supports Configurable Pins Shows False, indicating configurable pins are not available on the EDS-MD
device server.
Supports Email Triggers Shows True, indicating email triggers are available on the EDS-MD device
server.
Telnet Supported Indicates whether Telnet is enabled on this EDS-MD device server.
Telnet Port Shows the EDS-MD port for Telnet sessions.
