7: Line and Tunnel Settings
EDS-MD® Medical Device Server User Guide 46
Table 7-1 Line Configuration Settings
Line Settings Description
Name Enter a name or short description for the line, if desired. By default, there is
no name specified. A name that contains white space must be quoted.
State Select to enable or disable the operational state of the Line. The default is
Enabled.
Protocol Set the operational protocol for the Line. The default is Tunnel. Choices are:
None
Tunnel = Serial-Network tunneling protocol.
Baud Rate Set the Baud Rate (speed) of the Line. The default is 9600.
Any set speed between 300 and 921600 may be selected: 300, 600, 1200,
2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800, 921600.
When selecting a Custom baud rate, you may manually enter any value
between 300 and 5000000.
Note: Custom baud rates are not supported when a line is configured for
Command Mode.
Parity Note: Set the Parity of the Line. The default is None.
Data Bits Note: Set the number of data bits for the Line. The default is 8.
Stop Bits Note: Set the number of stop bits for the Line. The default is 1.
Flow Control Note: Set the flow control for the Line. The default is None.
Xon Char Set Xon Char to be used when Flow Control is set to Software. Prefix decimal
with \ or prefix hexadecimal with 0x or prefix a single control character
<control>.
Note: This field becomes available for configuration when Software is
selected under Flow Control.
Xoff Char Set Xoff Char to be used when Flow Control is set to Software. Prefix decimal
with \ or prefix hexadecimal with 0x or prefix a single control character
<control>.
Note: This field becomes available for configuration when Software is
selected under Flow Control.
Gap Timer Set the Gap Timer delay to Set the number of milliseconds to pass from the
last character received before the driver forwards the received serial bytes.
By default, the delay is four character periods at the current baud rate
(minimum 1 msec).
Threshold Set the number of threshold bytes which need to be received in order for the
driver to forward received characters.
