7
Illustrated Parts List
7-11
Item
No.
Part Number Qty. Description Remarks
1 1009873 1 Under Carriage, 8515, Rubber (Left)
2 1009874 1 Under Carriage, 8515, Rubber (Right)
3 811362 1 Motor, Hydraulic, Drive, 2 Speed
4 1008779 1 Torque Hub, 47.6:1, w/Brake
5 1009464 1 Sprocket, Track Drive, 17 Tooth Rubber Track Only
6 1009466 1 Weldment, Undercarriage (Right) Rubber Track Only
7 1009465 1 Weldment, Undercarriage (Left) Rubber Track Only
8 851566 2 Track Roller, B/1 Rubber Track Only
9 811331 2 Cylinder, Hydraulic, Track Tensioner Rubber Track Only
REF 811331-01 A/R Seal Kit Not Shown
10 811329ASRV 2 Yoke, Track Idler
11 983530 2 Idler, Track Front Rubber Track Only
12 982585 2 Track, Rubber, Continuous
13 870307 2 Hair Pin Cotter, .177
14 983588 3 Track Roller, B-1, Inner Flange Rubber Track Only
15 100-10-11-20-8F 12 CSHH, 5/8-11 x 1.25, GR8, FT
16 81201 7 Washer, Flat, SAE, 5/8
17 100-10-11-32-8 7 CSHH, 5/8-11 x 2.00, GR8
18 811328 20 Washer, Lock, M12
19 811330A 12 CSHH, M12x1.50 x 50mm
20 989272-36 4 CSHH, M10x1.50 x 30mm
21 320142 4 Washer, Lock, M10
22 811366 A/R O-Ring, Hydraulic Motor
23 100-8-13-28-5 2 CSHH, 1/2-13 x 1.75, GR5
24 302-8 2 Washer, Lock, 1/2
25 59941203 A/R Seal, Hydraulic Motor/Pump
26 851644 1 Breather, Track Tensioner Cylinder
REF 983166 A/R Assembly, Track, One Side 30 Pads per side
REF 987694 A/R Spacer, Roller, 8515 Not Shown, (2) Per Roller
REF 983166-02 A/R Track Pad, Poly, Heavy Duty Not Shown *
REF 983166-03 A/R Chain Rail, Track Drive, Heavy Duty Not Shown *
REF 983166-04 A/R Pin, Track Link, Master, Heavy Duty Not Shown *
REF 983166-05 A/R Kit, Track, Heavy Link Not Shown *
REF 983166-06 A/R CSHH, 135mm, Track Pad Bolt Not Shown *
*Used only in place of rubber tracks.
Rubber Track Undercarriage - 5 Roller Undercarriage
