LeeBoy 8515D - Page 223

7
Illustrated Parts List
7-13
Item
No.
Part Number Qty. Description Remarks
REF 851626SRV 1 Assembly, Conveyor, Complete Not include 1,2,3,4,10,11
REF 851627SRV 1 Assembly, Bed, 8500 Conveyor Not Shown
1 100-8-13-32-5 2 CSHH, 1/2-13 x 2.00, GR5
2 851112 2 Washer, Counter Sunk, .500
3 851473 2 Sprocket, Outer Drive
4 851483SRV 2 Conveyor Mounting Plate w/Bearing
5 851474SRV 2 Sprocket, Outer Drive C-188
6 850030 2 Sprocket, Inner Drive C-188
7 850130 20 Bearing, Auger, Axle, Idler
8 851116 2 Drive Shaft, Conveyor
9 850040 2 Snap Ring, Conveyor Drive Shaft
10 100-8-13-16-5F A/R CSHH, 1/2-13 x 1.00, GR5, FT
11 302-8 2 Washer, Lock, 1/2
12 851117ASRV A/R Assembly, Conveyor Chain
13 850070A 4 Link, Master w/Pins
14 850080A A/R Block Link
15 851127LSRV A/R Belly Pan (Left)
16 851127RSRV A/R Belly Pan (Right)
17 850215A A/R Half Link, Conveyor Chain w/Pin, Cotter
18 851118A A/R Bar, Conveyor Flight Bar (Quick Change) Thick side towards screed
19 850080B A/R Link w/Tab Conveyor Chain Inner
REF 851118-2 A/R Tab, Conveyor Chain Weld On Replacement, Not Shown
20 851118-1 2 Pin, Roll Pin (3/8 x 2.00)
21 1005803 2 Hydraulic Motor, Conveyor Main
REF 1001027-01 A/R Seal Kit, Hydraulic Motor Not Shown
22 851120 2 Sprocket, Conveyor Drive Motor
23 851121 2 Chain, Conveyor Drive (#80)
24 100-10-11-20-5F A/R CSHH, 5/8-11 x 1.25, GR5, FT
25 302-10 A/R Washer, Lock, 5/8
26 850038LSRV A/R Deector, Left Side (High Deck)
REF 850038RSRV 4 Deector, Right Side (High Deck) Not Shown
27 850040 4 Snap Ring, Conveyor Drive Shaft
28 850120 4 Idler, Conveyor Chain Front
29 851123 2 Assembly, Tube, Conveyor Front Chain Guide
29A 100-10-11-32-5 4 CSHH, 5/8-11 x 2.00, GR5
30 851124 2 Shaft, Conveyor Front Idler
31 850162 4 Roller, Conveyor Chain Guide, w/ Bearing
Conveyor Drive Assembly (1 of 2)
