Illustrated Parts List
7-17
Hopper Components (1 of 2)
Item
No.
Part Number Qty. Description Remarks
1 980703SRV 1 Assembly, Side Wing, 8515 (Right)
2 980702SRV 1 Assembly, Side Wing, 8515 (Left)
3 610110 2 Cylinder, Hydraulic, 2.00 x 8.00
REF 910145-01 A/R Seal Kit Not Shown
REF 930041 A/R Side Wing Cylinder Bushing Not Shown
4 851132 2 Pin
5 870307 4 Hair Pin, Cotter, .177
6 300-16 2 Washer, Flat, SAE, 1
7 851133SRV 1 Shield, 8500 Center Conv.
8 802112SRV 1 Hold Down
9 840162 1 Center Shield, Conveyor Rear
10 100-6-16-12-5F 6 CSHH, 3/8-16 x .75, GR5, FT
11 985669SRV 1 Shield, Front Support
12 985057 2 Shield, Front Hard Rubber
13 985062SRV 1 Clamp, Hopper Front Flashing
14 854084SRV 4 Pin, Pivot Side Panel
15 851147A 2 Shield, Corner Rubber
15A 854076-1 2 Plate, Side Wing Rubber Shield
16 988049 1 Bottom Tank
17 987264SRV 1 Safety Prop, Hopper
18 840020 1 Cylinder, Hopper Lift
REF 38549-01 A/R Seal Kit, Hopper Wing Not Shown
19 240030 2 Pin, Hydraulic Cylinder
20 840157SRV 1 Hinged Panel (Left)
21 840156SRV 1 Hinged Panel (Right)
REF 100-10-11-20-8F A/R CSHH, 5/8-11 x 1.25, GR8, FT Hold down for item 20,21
REF 301-10 A/R Washer, Flat, USS, 5/8 Hold down for item 20,21
22 920032SRV 2 Assembly, Guide Bar
23 920041SRV 2 Bar, Guide (Outer)
24 920051SRV 2 Housing, Guide Bar (Inner)
25 920061SRV 2 Rod & Chain, Guide Bar
26 920070 4 Thumb Screw, 3/8-16 x 1.00
27 985058 1 Rubber, Front Lip, Center
28 985063SRV 1 Flashing, Center, Front Lip
29 1013152 1 Weldment, Lip, Right, Front
30 1013153 1 Weldment, Lip, Left, Front
31 853595 2 Bar, 125 x 1.50 x 9.50
