7
Illustrated Parts List
7-23
Item
No.
Part Number Qty. Description Remarks
1 1005803 2 Hydraulic Motor, Conveyor Main
2 851148SRV 4 Bolt, Conveyor Drive Chain Adjuster
3 851149SRV 2 Mount, Conveyor Drive Motor
4 851121 2 Chain, Conveyor Drive (#80)
5 851120 2 Sprocket, Conveyor Drive Motor
6 100-8-13-32-5 8 CSHH, 1/2-13 x 2.00, GR5
7 200-8-13-5 8 Nut, Hex, 1/2-13, GR5
8 854532SRV 1 Chain Guard, Conveyor Drive (Left)
REF 853572SRV 1 Chain Guard, Conveyor Drive (Right) Not Shown
9 80338 4 Cotter Pin, .188 x 2.00 Long
10 302-6 6 Washer, Lock, 3/8
11 100-6-16-12-5F 6 CSHH, 3/8-16 x .75, GR5, FT
12 851436SRV 2 Hydraulic Cylinder, Screed Lift
REF 910145-01 A/R Seal Kit, 2.00 Cylinder Not Shown
13 302-16 2 Washer, Lock, 1
14 100-16-14-48-8 2 CSHH, 1-14 x 3.00, GR8
15 204-16-14-5 2 Nut, Lock, Stover,1-14, GR5
16 100-16-14-56-5 2 CSHH, 1-14 x 3.50 GR5
17 851152 2 Plate, Cut Off Cylinder Mount
18 100-10-11-24-5F 6 CSHH, 5/8-11 x 1.50, GR5, FT
19 302-10 6 Washer, Lock, 5/8
20 240030 2 Pin, Hydraulic Cylinder
21 910170 2 Hydraulic Cylinder, Cutoff
REF 910170-01 A/R Seal Kit, 2.50 Cylinder Not Shown
22 851153SRV 1 Cutoff (Left)
23 851154SRV 1 Cutoff (Right)
24 100-4-20-16-5F 2 CSHH, 1/4-20 x 1.00, GR5,FT
25 302-4 2 Washer, Lock, 1/4
26 860036 2 Washer, Fender, 1/4 x 1
27 853497 2 Plate, 8000-8500, Cut Off Cylinder Mount
28 853593SRV 2 Bar, .250 x 2.00 x 7.00
29 853596 2 Plate, Cut Off Gusset
Conveyor Drive Cutoff / Screed Lift Cylinders
