LeeBoy 8515D - Page 251

7
Illustrated Parts List
7-41
Item
No.
Part Number Qty. Description Remarks
1 851206SRV 1 Extension, Screed Arm
2 984896SRV 1 Assembly, Screed Arm, 8515 (Right)
REF 984897SRV 1 Assembly, Screed Arm, 8515 (Left) Not Shown
3 851209SRV 1 Mount, Pivot
4 851518 2 Screw, Electric (6.00”)
REF 35193 2 Connector, Sealed, Tower, 2-Pin Not Shown
REF 36165 4 Terminal, Sealed Connector, 16-14 GA, Female Not Shown
REF 36166 4 Seal, Cable, 18-16 GA, Green Not Shown
5 851210 2 Ears, Pivot
6 851211 1 End, Rod End of Screw
7 851212 1 End, Motor End of Screw
8 851213 1 Clevis, .188 x .250
9 851520 1 Cable, Height Locator .188 x 90 w/5.00” Stroke
10 851215 1 Decal, Height
11 100-16-8-40-5 1 CSHH, 1-8 x 2.50, GR5
12 204-8-13-5 1 Nut, Lock Stover, 1-8, GR5
13 100-10-11-40-5 3 CSHH, 5/8-11 x 2.50, GR5
14 204-10-11-5 3 Nut, Lock, Stover, 5/8-11, GR5
15 100-6-16-12-5F 2 CSHH, 3/8-16 x .75, GR5, FT
16 308-6-24 2 Washer, Flat, Fender, 3/8 x 1.50
17 100-4-20-32-5 1 CSHH, 1/4-20 x 2.00, GR5
18 204-4-20-5 1 Nut, Lock, Stover, 1/4-20, GR5
19 100-8-13-28-5 2 CSHH, 1/2-13 x 1.75, GR5
20 204-8-13-5 2 Nut, Lock, Stover, 1/2-13, GR5
21 855568 1 Bracket, Grade Control
22 853586SRV 1 Mounting Plate 6” Electric Screw, RH
REF 853585SRV 1 Mounting Plate 6” Electric Screw, (Left) Not Shown
23 987909 1 Fitting, 90° 06MJ-06MP, .078 Orice
Screed Arm Assembly With Toe Point
