LeeBoy 8515D - Page 313

7
Illustrated Parts List
7-103
Item
No.
Part Number Qty. Description Remarks
1 851241SRV 2 Housing, Rear Slide Bar
2 851242SRV 2 Bar, Adjustable Slide
3 920070 2 Thumb Screw, 3/8-16 x 1.00
4 851243SRV 2 Housing, Front Slide Bar
5 204-8-13-5 2 Nut, Lock, Stover, 1/2-13, GR5
6 851249SRV 2 Skid
7 100-8-13-40-5 2 CSHH, 1/2-13 x 2.50, GR5
8 981981 2 Aluminum Cable Sleeve .0625
9 851245 1 Spring, Tension
10 851246 1 Cable 1.0625
11 851247SRV 1 Arm, Skid Support (Rear)
12 851248SRV 1 Arm, Skid Support (Front)
13 100-10-11-40-5 1 CSHH, 5/8-11 x 2.50, GR5
14 204-10-11-5 1 Nut, Lock, Stover, 5/8-11, GR5
15 851578 1 Bracket, Sonic Tracker
16 300-10 2 Washer, Flat, SAE, 5/8
17 100-10-11-64-5 1 CSHH, 5/8-11 x 4.00, GR5
18 987053SRV 1 AM Module/Cable Assembly, w/Base Plate
REF 985866-01 1 AM Module Only Not Shown
REF 985866-02 1 Cable, AM Module Only Not Shown
REF 984596 1 Assembly, Cord Remote Not Shown
19 851579 1 Sonic Tracker
20 851581 1 Wire Bail, Temperature
21 851265 1 Case, Sonic Tracker
22 851575SRV 2 Pivot Mount, TopCon/Spectra Physics
23 9090-1125SRV 1 Bracket, Z Arm, TopCon
24 300060 1 Handle, Bolt, 5/8-11
25 100-10-11-20-5F 1 CSHH, 5/8-11 x 1.25, GR5, FT
26 851421 A/R Slope Meter
27 851574 A/R Coiled Cord, TopCon Tracker/Slope
REF 851584SRV 1 Assembly, 20 FT. Kit Not Shown
REF 851585SRV 1 Assembly, 30 FT. to 40 FT. Kit Not Shown
30 984596 1 Assembly, Cable Remote Plugs into item 18
Paver Leveling Control TopCon System 4 (Option)
