7
Illustrated Parts List
7-107
Item
No.
Part Number Qty. Description Remarks
REF 1000253SRV 1 Assembly, Truck Hitch Not Shown
1 930015 1 Support, Pivot Bar
2 930020SRV 1 Arm Extension (Right)
3 930025SRV 1 Arm Extension (Left)
4 930030SRV 2 Arm, Assembly, Truck Hitch Wheel Pivot
5 620400 4 Collar, Lock
6 810070 4 Bushing, 2.00 ID x 2.50 OD x 2.50
7 930040 2 Roller
8 930045SRV 2 Assembly, Axle, Guide Wheel
9 930050 2 Bearing, Truck Hitch Roller
10 930055 2 Guide Wheel, Truck Hitch
11 100-8-13-32-5 2 CSHH, 1/2-13 x 2.00, GR5
12 810102 2 Push Roller, Truck Wheel
13 810110 8 Bearing, Push Roller (1.25)
14 930060 2 Roller Extension, Bumper
15 930065 1 Cover, Back Panel
16 930070 1 Cylinder, Arm Extension
REF 930070-01 1 Seal Kit Not Shown
REF 852250 1 Valve Truck Hitch Not Shown
17 930075 2 Shaft, Bumper Roller
18 851112 2 Washer, Counter Sunk, 1/2
REF 984399 1 Hose Kit 8515 Truck Hitch Not Shown
REF 852250 1 Selector Valve, Conveyor Not Shown
Truck Hitch Assembly (Option)
