LeeBoy 8515D - Page 323

7
Illustrated Parts List
7-113
Item
No.
Part Number Qty. Description Remarks
1 1007195 1 Group, Screed Frame, 815HD
2 983157 1 Assembly, Turnbuckle W/Ratchet
3 980182 1 Assembly, Crown & Valley, Rear
4 1008047 1 Chain, Roller, 60H x 39 Pitches
REF 853411 1 Link, Master, #60 Chain
5 985125 2 Cover, Elements, Screed Base
6 981659 2 Pin, Slope
7 981711 2 Plate, Pivot Cover
8 981661 2 Pin, Cylinder Mount
9 985121 4 Bar, Element Hold Down
10 1007275SRV 4 Element, Heater, 46", 1000W
11 1007002 2 Cover, Rear Elements
12 1007089SRV 1 Wearplate, 3/8" Wear Plate With Studs Not Include 9, 10, 11, 27,28
13 1008663 1 Weldment, Rail Mount (Left)
14 1008662 1 Weldment, Rail Mount (Right)
15 1006425 2 Bar, V-Groove Top Rail
16 1006426 2 Bar, V-Groove Bottom Rail
17 985149 2 Cover, Screed Elements
18 1008758 1 Assembly, Upper Screed Cover (Right)
19 1008757 1 Assembly, Upper Screed Cover (Left)
20 1007000 1 Cover, Screed Lower (Left/Right)
21 981710R 1 Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25
22 981710L 1 Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25
23 983421 2 Cylinder, Hydraulic, 2.75 x 2.00 x 1.125 Rod
24 100-5-18-8-5F 4 CSHH, 5/16-18 x .50, GR5, FT
25 302-5 34 Washer, Lock, 5/16
26 100-5-18-24-5 18 CSHH, 5/16-18 x 1.50, GR5
27 200-8-13-5 36 Nut, Hex, 1/2-13, GR5
28 100-7-14-16-5F 20 CSHH, 7/16-14 x 1.00, GR5, FT
29 302-7 20 Washer, Lock, 7/16
30 100-8-13-32-5 12 CSHH, 1/2-13 x 2.00, GR5
31 200-8-13-5 12 Nut, Hex, 1/2-13, GR5
32 1015015SRV 1 Element, Heating, 250W/240V, 11” Complete
815HD Series Screed Frame Sloping
