7
Illustrated Parts List
7-119
Item
No.
Part Number Qty. Description Remarks
1 987056SRV 1 Assembly, Walkboard - Long
2 985163 2 Plate, Walkboard Hinge
3 100-8-13-20-5F 2 CSHH, 1/2-13 X 1.25, GR5, FT
4 302-8 2 Washer, Lock, 1/2
5 200-8-13-5 2 Nut, Hex, 1/2-13, GR5
6 985549 2 Latch, Walkboard
REF 250170 2 Spring, Extension Use with Item 6
815HD Series Walk Board Assembly
