Illustrated Parts List
7-125
Item
No.
Part Number Qty. Description Remarks
1 1006380SRV 1 Assembly, Extension Heatbox Not Include 4, 5
2 1008665SRV 1 Weldment, Heatbox Cover
3 985123 3 Clamp, Element, Screed Extension
4 985120 1 Bar, .25 x 1.5 x 36
5 987890SRV 1 Element, Heater, Screed, 41"
6 1006379SRV 1 Assembly, Screed Extension, Slope (Right) Includes all items
7 1006400 1 Plate, Extension Strikeoff
8 1006395 2 Bar, Vertical Lift
9 1008664 1 Weldment, Extension Vibrator Cover
10 1006398 1 Plate, Extension Access Cover
11 854447SRV 1 Round, .688 x 43.50 CRS
12 1006398 2 Bar, Vertical Lift Gauge
13 1007098 1 Assembly, Outer Extension Mount (Right)
14 1007099 1 Assembly, Inner, Extension Mount (Right)
15 1006536 1 Plate, Endgate Bracket w/Holes
16 1006390 2 Assembly, Vertical Lift Adjust
17 1006401 1 Assembly, AOA Adjuster
18 1000947 1 Ball Joint, .750, Male
19 100-5-18-40-5 14 CSHH, 5/16-18 x 2.50, GR5
20 302-5 24 Washer, Lock, 5/16
21 100-6-16-16-5F 14 CSHH, 3/8-16 x 1.00, GR5, FT
22 302-6 14 Washer, Lock, 3/8
23 100-7-14-20-5 3 CSHH, 7/16-14 x 1.50, GR5
24 302-7 3 Washer, Lock, 7/16
25 200-7-14-5 3 Nut, Hex, 7/16-14, GR5
26 200-6-16-5 6 Nut, Hex, 3/8-16, GR5
27 100-5-18-12-5F 10 CSHH, 5/16-18 x .75, GR5, FT
28 870030 3 Bearing, Screed Flight Screw
815HD Series Extension Assembly (Right)
