LeeBoy 8515D - Page 341

7
Illustrated Parts List
7-131
Item
No.
Part Number Qty. Description Remarks
1 984534L 1 Enclosure, Electric 3 Switch, Lower Control (Left) Sloping Extenion
1a 984535L 1 Enclosure, Electric 2 Switch, Lower Control (Left) Non-Sloping Extension
2 1006437SRV 1 Assembly, Screed Arm, Slope (Left)
3 1011374SRV 1 Assembly, Thickness
4 1011375 1 Weldment, Thickness Adjuster Handle
5 810110 2 Bearing Roller, 1-1/4”
6 20931333 1 Washer, 13/16
7 95200978 1 Washer, Lock, Thin Series
8 95200879 1 Nut, Lock
9 1011309 1 Key, .25 x .25 x 1.25
10 1011373 1 Assembly, Lower Thickness Adjuster
11 981574 2 Knob, Revolving Ball, M12x1.75
12 1006434 1 Cap, Adjuster Handle
13 95998936 1 Locknut, PTORQ, 3/4-16
14 301-12 1 Washer, Flat, 3/4
15 200-M12-1.75-8.8 2 Nut, Hex, M12x1.75, C 8.8
16 302-M12 2 Washer, Lock, M12
17 100-4-20-12-5F 2 CSHH, 1/4-20 x .75, GR5, FT
18 300-4 2 Washer, Flat, SAE, 1/4
19 200-4-20-5 2 Nut, Hex, 1/4-20, GR5
20 984533-03L 1 Enclosure, Electric, 4x4x3, 3 Holes (Left)
21 851391 1 Switch, Toggle, SPST, 2-Position
22 851393 1 Switch, Toggle, SPDT, 3-Position, MOM LK
23 851392 1 Switch, Toggle, SPDT, 3-Position, MOM
24 100-6-16-8-5F 4 CSHH, 3/8-16 x .50, GR5, FT
25 302-6 4 Washer, Lock, 3/8
26 200-6-16-5 4 Nut, Hex, 3/8-16, GR5
27 851373SRV 1 Lock Arm, Flight Screw
28 1007677-01 1 Decal, Thicker/Thinner
29 859784 1 Decal, Auger Extension (Left)
30 856647 1 Decal, Elite III Dash (Left)
815HD Series Screed Pull Arms Assembly (Left)
