Illustrated Parts List
7-137
Item
No.
Part Number Qty. Description Remarks
1 1008168 1 Cover, Power Crown
2 1008667 1 Weldment, Power Crown Center
3 1008600 1 Plate, Power Crown Adjuster Not include bushing
REF 1000960 1 Bushing, Composite, Power Crown
4 986640 1 Motor, Hydraulic, Danfoss
5 1008668SRV 1 Assembly, Crown And Valley Front
6 980182 1 Assembly, Crown & Valley, Rear Not include item # 7
7 1000798 2 Collar, Power Crown Locking
8 1008047 1 Chain, Roller, 60H x 39 Pitches
9 1000958 1 Chain, Roller, 50 x 18
10 1006419 2 Spacer, Crown Mount
11 1000799 1 Sprocket, #50 Roller Chain
12 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT
13 302-6 2 Washer, Lock, 3/8
14 100-8-13-16-5F 6 CSHH, 1/2-13 x 1.00, GR5, FT
15 302-8 6 Washer, Lock, 1/2
16 200-8-13-5 6 Nut, Hex, 1/2-13, GR5
17 100-8-13-20-5F 2 CSHH, 1/2-13 x 1.25, GR5, FT
18 302-8 2 Washer, Lock, 1/2
19 200-8-13-5 2 Nut, Hex, 1/2-13, GR5
REF 920238-3 A/R Cover, 3/4” Condulet
REF 920238-2 A/R Condulet, 3/4” Aluminum
REF 920238-4 A/R Gasket, Condulet Box, 3/4”
REF 920238-5 A/R Aluminum Plug, 3/4” Condulet
REF 3400DI A/R Water Tight Connection, 3/4” X 3/4”
20 1000059 2 Vibrator, Hydraulic
21 72884 A/R Switch, Toggle, SPST, 2-Position, MOM
815HD Series Screed Optional Components
