Alphabetical Parts Index
LeeBoy Model 8515D Conveyor Paver7-156
Description Part No. Figure No. Item No.
Assembly, Side Wing, 8515 (Left) 980702SRV 7-4 2
Assembly, Side Wing, 8515 (Right) 980703SRV 7-4 1
Assembly, Slide Adjust 985556SRV 7-26 4
Assembly, Slide Adjust 985556SRV 7-27 4
Assembly, Slide Adjust 985556SRV 7-32 4
Assembly, Slide Adjust 985556SRV 7-33 4
Assembly, Slide Plate 1002181 7-41 2
Assembly, Slide Plate, w/Chrome Rods 1002186 7-41 1
Assembly, Slide w/o Shafts 1006445 7-55 2
Assembly, Slide w/Shafts, HD 1006416 7-55 1
Assembly, Spacer Auger Shaft 982945 7-5 11
Assembly, Tank, Fuel, 8515 1009361 7-7 7
Assembly, Tank, Hydraulic, 8515 1003410SRV 7-7 5
Assembly, Test Port REF 7-13 33
Assembly, Thickness 1011374SRV 7-60 3
Assembly, Thickness 1011374SRV 7-61 3
Assembly, Tilt Screw, Endgate 890081SRV 7-58 6
Assembly, Tilt Screw, Endgate 890081SRV 7-59 6
Assembly, Tilt Screw, Jointer 890081SRV 7-34 12
Assembly, Tilt Screw, Jointer 890081SRV 7-35 12
Assembly, Track, One Side 983166 7-2 REF
Assembly, Track, One Side, w/Poly Pads 851101P 7-1 1
Assembly, Truck Hitch 1000253SRV 7-48 REF
Assembly, Tube, Conveyor Front Chain Guide 851123 7-3 29
Assembly, Tube, Conveyor Rear Drive 851651 7-3 32
Assembly, Turnbuckle W/Ratchet 983157 7-51 2
Assembly, Turnbuckle W/Ratchet 983157 7-52 2
Assembly, Upper Screed Cover (Left) 1008757 7-51 19
Assembly, Upper Screed Cover (Left) 1008757 7-52 16
Assembly, Upper Screed Cover (Right) 1008758 7-51 18
Assembly, Upper Screed Cover (Right) 1008758 7-52 15
Assembly, Vertical Lift Adjust 1006390 7-56 16
Assembly, Vertical Lift Adjust 1006390 7-57 16
Assembly, Vibrator (Left) 982965LSRV 7-39 1
Assembly, Vibrator (Left) 982965LSRV 7-53 1
Assembly, Vibrator (Right) 982965RSRV 7-39 REF
Assembly, Vibrator (Right) 982965RSRV 7-53 7
Assembly, Walk Board, Long 987056SRV 7-40 4
Assembly, Walkboard - Long 987056SRV 7-54 1
Assembly, Wear Plate, Electric 987216SRV 7-28 13
