LeeBoy L600 - Page 105

Component Layout
Item
No.
Part Number Qty. Description Remarks
1 1009318-00-02 1 Pintle Eye
2 100-10-11-72-8 2 CSHH, 5/8-11 x 4.50, GR8
3 205-10-11-8 2 Nut, Lock, Nylon, 5/8-11, GR8
4 1009317-00-06 2 Safety Chain
5 1009317-00-07 2 Chain Connector
6 1007536 2 Hook w/Clevis & Clasp
7 32884 1 Jack, Screw Type, 5000#
8 1020061-11 1 Cover, Manhole
9 510200A 1 Coupler, 2" Ball, Adjustable
OPTION
10 985234 1 Manual Case
GRP 1021171 1 Group - Electrical, L300
Includes Items 11-17A
GRP 1022285 1 Group - Electrical, L600
Includes Items 11-16,17B
11 1015305 1 Kit, Tail Light, LED, Brake/Turn/Side Marker
Includes (2) Side Markers, LH/RH Tail
12 1021170 1 Kit, Breakaway, 12V
13 100-4-20-16-5F 3 CSHH, 1/4-20 x 1.00, GR5, FT
Not Shown
14 302-4 3 Washer, Lock, 1/4
Not Shown
15 300-4 3 Washer, Flat, SAE, 1/4
Not Shown
16 31893 1 Bracket, License Plate
Not Shown
17A 1020501 1 Harness, Main, L300
Not Shown, Ref Section 6-Schematics
17B 1022298 1 Harness, Main, L600
Not Shown, Ref Section 6-Schematics
GRP 1021179 1 OPTION - Mount, Waste Bucket
Includes Items 18,19,21,22
18 1021068 1 Mount, Waste Bucket
19 100-6-16-20-5 2 CSHH, 3/8-16 x 1.25, GR5
20 100-6-16-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT
(4) Not Shown
21 302-6 6 Washer, Lock, 3/8
(4) Not Shown
22 301-6 6 Washer, Flat, USS, 3/8
(4) Not Shown
23 1020911 1 Step
24 150090A 2/4 Tire & Wheel Assembly
L600 Uses (4) Assemblies
25 150040B 1/2 Axle Assembly w/Brake, 5200#
L600 Uses (2) Axles
26 1019662 2 Decal, Deco, Leeboy
27A 1021997 1 Decal, Deco, LeeBoy, 300 Tack Tank
27B 1021998 1 Decal, Deco, LeeBoy, 600 Tack Tank
28A 1021885 2 Decal, Deco, L300, White
28B 1021886 2 Decal, Deco, L600, White
29 See Fig 7-15 Group - LP Burner
30
See Fig 7-12/Fig. 7-13
Group - Engine Assembly
31 See Fig 7-7 Assembly, Valve, Selector/Operation
32 See Fig 7-11 Group - Spray Wand
33 See Fig 7-3 Exhaust
34 See Fig 7-6 Group - Flush Tank
35 See Fig 7-2 Contents Gauge - Rear
36 See Fig 7-2 Contents Gauge - Front
37 See Fig 7-9 Assembly, Valve, Drain
38 See Fig 7-8 Assembly, Valve, Liquid Asphalt/Flush
L300 and L600 Tack Distributors
Illustrated Parts List
7-5
