Contents Gauge Details
Item
No.
Part Number Qty. Description Remarks
Contents Gauge - Front
Includes Items 1-6
1 1021551 1 Pointer, Contents Gauge
2 114-4-20-8 1 Set Screw, SQ HD, Cup, 1/4-20 x .50
3 8119-2 1 Collar, Shaft, Split, .50 ID x 1.12 OD
4 29093 1 Nut, Float Rod Pivot, .188 Seal
5 39084 1 O-Ring, #310, .18 x .50 ID, Viton
6A 1021558 1 Decal, Info, Contents Gauge, Front, L300
6B 1022343 1 Decal, Info, Contents Gauge, Front, L600
Contents Gauge - Rear
Includes Items 1-5,7
1 1021551 1 Pointer, Contents Gauge
2 114-4-20-8 1 Set Screw, SQ HD, Cup, 1/4-20 x .50
3 8119-2 1 Collar, Shaft, Split, .50 ID x 1.12 OD
4 29093 1 Nut, Float Rod Pivot, .188 Seal
5 39084 1 O-Ring, #310, .18 x .50 ID, Viton
7A 1021559 1 Decal, Info, Contents Gauge, Rear, L300
7B 1022344 Decal, Info, Contents Gauge, Rear, L600
L300 and L600 Tack Distributors
Illustrated Parts List
7-7
