Axle Assembly - L300
Item
No.
Part Number Qty. Description Remarks
L300 Axle Assembly
1 1009318-00-01 1 Axle Assembly, Brake 5200#
Complete Assembly
2 150050A 2 U-Bolt Kit 5200#
3 150060A 2 Spring, Axle 5200#
4 317030 2 Brake Drum Assembly, 5200#
Includes items 5-16R/16L
5 610190 2 Wheel Seal 5200#
(1) Per Drum Assembly
6 610200 2 Cup, Roller Bearing
(1) Per Drum Assembly
7 610210 2 Cone, Roller Bearing
(1) Per Drum Assembly
8 610230 2 Cup, Roller Bearing
(1) Per Drum Assembly
9 610240 2 Cone, Roller Bearing
(1) Per Drum Assembly
10 610250-1 2 D-Washer
(1) Per Drum Assembly
11 610250 2 Lockwasher
(1) Per Drum Assembly
12 610260 2 Axle Nut
(1) Per Drum Assembly
13 340040 2 Grease Cap 5200#
(1) Per Drum Assembly
14 120340 12 Wheel Stud
(6) Per Drum Assembly
15 981739 12 Lug Nut
(6) Per Drum Assembly
16R 340060R 1 Brake Assembly 5200R
Includes items 17 thru 20
16L 340060L 1 Brake Assembly 5200L
Includes items 17 thru 20
17 340070 2 Brake Shoe Kit 12 X 2
(1) Per Brake Assembly
18 340110 2 Brake Adjuster
(1) Per Brake Assembly
19 340100 2 Electromagnet
(1) Per Brake Assembly
20 340130 2 Spring Kit
(1) Per Brake Assembly
21 1009319-00-02 2 Assembly, Link
22 1009319-00-01 2 Link, Shackle
23 1009317-00-03 2 Bolt, Shackle
24 1009317-00-04 6 Locknut, Flanged
L300 and L600 Tack Distributors
Illustrated Parts List
7-11
