Axle Assembly - L600
Item
No.
Part Number Qty. Description Remarks
L600 Axle Assembly
1 1009318-00-01 2 Axle Assembly, Brake 5200#
Complete Assembly
2 150050A 4 U-Bolt Kit 5200#
3 150060A 4 Spring, Axle 5200#
4 317030 4 Brake Drum Assembly, 5200#
Includes items 5-16R/16L
5 610190 4 Wheel Seal 5200#
(1) Per Drum Assembly
6 610200 4 Cup, Roller Bearing
(1) Per Drum Assembly
7 610210 4 Cone, Roller Bearing
(1) Per Drum Assembly
8 610230 4 Cup, Roller Bearing
(1) Per Drum Assembly
9 610240 4 Cone, Roller Bearing
(1) Per Drum Assembly
10 610250-1 4 D-Washer
(1) Per Drum Assembly
11 610250 4 Lockwasher
(1) Per Drum Assembly
12 610260 4 Axle Nut
(1) Per Drum Assembly
13 340040 4 Grease Cap 5200#
(1) Per Drum Assembly
14 120340 24 Wheel Stud
(6) Per Drum Assembly
15 981739 24 Lug Nut
(6) Per Drum Assembly
16R 340060R 2 Brake Assembly 5200R
Includes items 17 thru 20.
16L 340060L 2 Brake Assembly 5200L
Includes items 17 thru 20
17 340070 4 Brake Shoe Kit 12 X 2
(1) Per Brake Assembly
18 340110 4 Brake Adjuster
(1) Per Brake Assembly
19 340100 4 Electromagnet
(1) Per Brake Assembly
20 340130 4 Spring Kit
(1) Per Brake Assembly
21 1009319-00-03 2 Equalizer
22 1009319-00-02 4 Assembly, Link
23 1009319-00-01 8 Link, Shackle
24 1009317-00-03 6 Bolt, Shackle
25 1009317-00-04 14 Locknut, Flanged
L300 and L600 Tack Distributors
Illustrated Parts List
7-13
