LeeBoy L600 - Page 117

Plumbing - Selector/Operation Valve
Item
No.
Part Number Qty. Description Remarks
GRP 1021859 1 Group - Plumbing, Non-Insulated Tank
Not All Items Shown, Includes 1-11
GRP 1021860 1 OPTION - Plumbing, Non-Insulated w/Overnight Heat
Not All Items Shown, Includes 1-11
ASSY 1021861 1 Selector/Operation Valve Assembly
Includes Items 1-4
1 1021050 1 Assembly, Valve
2 1021050-01 A/R Handle
3 6400-8-10-O 1 Adapter, Straight, -8 JIC/-10 O-Ring
4 2404-8-8 1 Adapter, Connector, -8 JIC/-8 NPTF
5 6801-8-10 NWO 1 Adapter, Elbow, 90°, -8 JIC/ -10 O-Ring
6 1021939 1 Spacer, Selector Valve
7 100-6-16-56-5 1 CSHH, 3/8-16 x 3.50, GR5
8 302-6 1 Washer, Lock, 3/8
9 300-6 1 Washer, Flat, SAE, 3/8
10 6505-8-8 1 Adapter, Male Pipe/Swivel, -8 NPTF/-8 JIC
11 1021940 1 Kit, Hose, Main
Not Shown, See Fig 7-10
GRP 1022080 1 OPTION - Plumbing, Insulated Tank
Not All Items Shown, Includes 1-4,6-9, 11-13
GRP 1022081 1 OPTION - Plumbing, Insulated w/Overnight Heat
Not All Items Shown, Includes 1-4,6-7, 11-132
ASSY 1022085 1 Selector/Operation Valve Assembly, Insulated
Includes Items 1-4,12
12 6809-10-8 NWO 1 Adapter, Elbow, 90°, Swivel, -10 O-Ring/-8 JIC
Replaces Item 5
13 2404-L-08-08 1 Adapter, Straight, Long, -8 JIC/-8 NPTM
Replaces Item 10
14 6801-8-10 NWO 1 Adapter, Elbow, 90°, -8 JIC/ -10 O-Ring
Added w/Spray Wand Group, See Fig 7-11
15 6801-LL-8-10 NWO 1 Adapter, Elbow, 90°, Extra Long, -8 JIC/-10 O-Ring
Added w/Spray Bar Option, Ref Fig 7-19
L300 and L600 Tack Distributors
Illustrated Parts List
7-17
