Plumbing - Drain Valve/Miscellaneous
Item
No.
Part Number Qty. Description Remarks
GRP 1021859 1 Group - Plumbing, Non-Insulated Tank
Not All Items Shown, Includes 1-6
GRP 1021860 1 OPTION - Plumbing, Non-Insulated w/Overnight Heat
Not All Items Shown, Includes 1-5
ASSY 1021862 1 Drain Valve Assembly, Non-Insulated Tank
Includes Items 1-4
1 1009927 1 Pipe, Nipple, 1" x 6", SCH40
2 32839 1 Fitting, 90°, -16 MP/-16MPX
3 280210 1 Ball Valve, 1.00", FM x FM
4 91277 1 Pipe, Nipple, 1.00" x Close
5 280300 1 Pipe, Plug, 4.00" MP, Bar HD
6 70444 1 Pipe, Plug, 2.00", SQ HD
GRP 1022080 1 OPTION - Plumbing, Insulated Tank
Not All Items Shown, Includes 1-3,5-6
GRP 1022081 1 OPTION - Plumbing, Insulated w/Overnight Heat
Not All Items Shown, Includes 1-3,5
ASSY 1021960 1 Drain Valve Assembly, Insulated Tank
Includes Items 1-3
7 2702-8-8-LN 1 Adapter, Bulkhead Elbow, 45°, -8 JIC/-8
Added w/Spray Wand Group, See Fig 7-11
8 2702-8-8-LN 1 Adapter, Bulkhead Elbow, 45°, -8 JIC/-8
Added w/Spray Bar Option, See Fig 7-19
9 2702-8-8-LN 1 Adapter, Bulkhead Elbow, 45°, -8 JIC/-8
Added In-Cab Controls Option, See Fig 7-20
10 150710SRV 1 OPTION - Overnight Heat, Electric
L300 and L600 Tack Distributors
Illustrated Parts List
7-21
