LeeBoy L600 - Page 123

Hose Assemblies
Item
No.
Part Number Qty. Description Remarks
KIT 1021940 1 Main Hose Kit
Includes Items 1-4
1 F387TC0606121212-43 1 Hose Assembly, 43" - 3 Way Valve to Pump
2 F387TC0606080808-35 1 Hose Assembly, 35" - Tee to Manifold D
3 F387TC0606080808-67 1 Hose Assembly, 67" - Pump RV to Manifold C
4 R801NRNR000008-19.25 1 Hose Assembly, 19.25" - Flush Tank to Ball Valve
KIT 1021966 1 Spray Wand Hose Kit, L300
Includes Items 5-6
5 F387TC0606080808-84 1 Hose Assembly, 84" - Manifold B to BH Fitting
6
F387TC0606080808-31.25
1 Hose Assembly, 31.25" - BH Fitting to Hose Reel
KIT 1021967 1 Spray Wand Hose Kit, L600
Includes Items 7-8
7 F387TC0606080808-144 1 Hose Assembly, 144" - Manifold B to BH Fitting
8 F387TC0606080808-35 1 Hose Assembly, 35" - BH Fitting to Hose Reel
KIT 1021972 1 OPTION - Spray Bar Hose Kit, L300
Includes Items 9-12
9 F387TC0606080808-96 1 Hose Assembly, 96" - Manifold A to BH Fitting
10 F387TC0606081008-48 1 Hose Assembly, 48" - BH Fitting to SB Tee
11 F387TC0606101008-45 1 Hose Assembly, 45" - SB Tee to LH Spray Bar
12 F387TC0606101008-46 1 Hose Assembly, 46" - SB Tee to RH Spray Bar
KIT 1021991 1 OPTION - Spray Bar Hose Kit, L600
Includes Items 10-13
10 F387TC0606081008-48 1 Hose Assembly, 48" - BH Fitting to SB Tee
11 F387TC0606101008-45 1 Hose Assembly, 45" - SB Tee to LH Spray Bar
12 F387TC0606101008-46 1 Hose Assembly, 46" - SB Tee to RH Spray Bar
13 F387TC0606080808-180 1 Hose Assembly, 180" - Manifold A to BH Fitting
KIT 1021985 1
OPTION - Spray Bar In-Cab Control Hose Kit, L300 Not Shown, See Fig 7-21
KIT 1021996 1
OPTION - Spray Bar In-Cab Control Hose Kit, L600 Not Shown, See Fig 7-21
L300 and L600 Tack Distributors
Illustrated Parts List
7-23
