LeeBoy L600 - Page 125

Spray Wand Group
Item
No.
Part Number Qty. Description Remarks
GRP 1021166 1 Group - Spray Wand
1 150020 1 Hose Reel Assembly
- 280110 1 Hose, Tack Spray, 1/2” ID x 40’
2 2501-8-8 1 Adapter, Elbow, 90°, -8 JIC/-8 NPTF
3 100-6-16-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT
4 302-6 4 Washer, Lock, 3/8
5 300-6 4 Washer, Flat, SAE, 3/8
6 280302 1 Wand, Tack Spray (Aluminum)
Includes Items 7-18
7 280310 1 Nozzle, Tack Spray Wand
8 1017480 1 Test Cock, Bronze, 1/4M x 1/4F
9 280320 1 Bushing, Hex Head, 1/2" x 1/4"
10 99512 1 Pipe, Elbow, 90°, 1/2"
11 851921 1 Pipe, Spray Wand
ASSY 851919 1 Assembly, Front Handle, Spray Wand
Includes Items 12-15
12 851919-03 1 Handle, Spray Wand
- 100-4-20-8-5F 1 CSHH, 1/4-20 x .50, GR5, FT
Included with Item 12
13 857056 2 Handle, Spray Wand
14 100-4-28-80-5 2 CSHH, 1/4-28 x 5.00, GR5
15 217-4-28 1 Nut, Lock, Flexloc, 1/4-28
ASSY 982483 1 Spray Wand Assembly
Includes Items 13-14,16-18
16 1017485 1 Ball Valve, 1/2"
`
- 200-5-18-5 1 Nut, Hex, 5/16-18, GR5
Included with Item 16
17 857055 1 Extension, Spray Wand On/Off
18 2004-4-28-5 1 Nut, Hex, 1/4-28, GR5
19 1021966 1 Hose Kit, Spray Wand
Not Shown, See Fig 7-10
20 6801-8-10 NWO 1 Adapter, Elbow, 90°, -8 JIC/-10 O-Ring
Not Shown, See Fig 7-7
21 2702-8-8-LN 1 Adapter, Bulkhead Elbow, 45°, -8 JIC/-8
Not Shown, See Fig 7-9
L300 and L600 Tack Distributors
Illustrated Parts List
