LeeBoy L600 - Page 127

Engines - Gas
Item
No.
Part Number Qty. Description Remarks
GRP 1020934 1 Group - Gas Engine, Pull Start
Includes Items 1,3-18,36
GRP 1020935 1 Group - Gas Engine, Electric Start
Includes Items 2-36
1 150200H 1 Engine, Honda, 5.5 HP
2 150200HE 1 Engine, Honda 5.5 HP, Electric Start
3 150160 1 Housing, Pump Couplings
4 851437 2 Clamp, Hose, #72 (4")
5 1002664 1 Cover, Pump Couplings
6 150150A 1 Coupling, Half, L-Type Jaw, 3/4" Bore w/Keyway
7 280040 1 Spider, L-Type Jaw Coupling
8 280050 1 Coupling, Half, L-Type Jaw, 1/2" Bore w/Keyway
9 2501-12-8 1 Adapter, Elbow, 90°, -12 JIC/-8 NPTF
10 5602-8-8-8 1 Adapter, Male Run Pipe Tee, -8 NPTF/-8 NPTF--8 NPT
11 280020A 1 Pump, Tack Spray (7 GPM)
12 280075 1 Pipe, Nipple, .50 x 2.50
13 280100 1 Valve, Relief
14 2501-8-8 1 Adapter, Elbow, 90°, -8 JIC/-8 NPTF
15 1020989 1 Assembly, Bypass
16 100-5-24-16-5 4 CSHH, 5/16-24 x 1.00, GR5
17 302-5 4 Washer, Lock, 5/16
18 300-5 4 Washer, Flat, SAE, 5/16
(Items 19 thru 35 are for Electric Start Option)
19 1020106 1 Cover, Battery
20 PURCHASE LOCALLY 1 Battery, 12VDC, 800CCA, Group 24
21 1020107 1 Plate, Hold Down, Battery
22 1019923 1 Cable
23 410070 1 Bumper
24 1020129 1 Stop, Battery Cover
25 920070 1 Thumb Screw, 3/8-16 x 1.00
26 100-6-16-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT
27 100-6-16-152-5 2 CSHH, 3/8-16 x 9.50, GR5
28 302-6 5 Washer, Lock, 3/8
29 300-6 8 Washer, Flat, SAE, 3/8
30 204-6-16-5 1 Nut, Lock, Stover, 3/8-16, GR5
31 100-4-20-12-5F 2 CSHH, 1/4-20 x .75, GR5, FT
32 302-4 2 Washer, Lock, 1/4
33 300-4 2 Washer, Flat, SAE, 1/4
34 1021461 1 Cable, Battery, (-) Eye/Eye, 4 AWG, 14"
Not Shown
35 1021462 1 Cable, Battery, (+) Eye/Eye, 4 AWG, 16"
Not Shown
36 SEE FIG. 7-14 1 Engine Cover & Engine Mount
Not Shown
L300 and L600 Tack Distributors
Illustrated Parts List
7-27
