LP Burner Group
Item
No.
Part Number Qty. Description Remarks
GRP 1021153 1 Group - LP Burner
1 230010-40 1 Propane Tank, 40#
2 230110 1 Gauge, Pressure, LPG
3 230030 1 POL Adapter, LPG Tank
4 1021151 1 Regulator, LPG, 597FC
5 1019014 3 Adapter, Elbow, 90°, -4 MNPTF "B"/ 9/16-18 LH, LPG
6 1020118 1 Mount, LP Tank
7 100-6-16-40-5 1 CSHH, 3/8-16 x 2.50, GR5
8 212-6-16 1 Wing Nut, 3/8-16
9 100-6-16-20-5 2 CSHH, 3/8-16 x 1.25, GR5
10 302-6 4 Washer, Lock, 3/8
11 301-6 6 Washer, Flat, USS, 3/8
12 1008652SRV 1 Burner, Wand Assembly
13 1021147 1 Mount, Wand, Burner
14 100-6-16-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT
15 1021572 1 Hose Assembly, LP Gas, 9/16-18 LH, 43" LP Regulator to LP Valves Assy
16 1021571 1 Hose Assembly, LP Gas, 9/16-18 LH, 29" LP Valves Assy to Burner Wand
17 1021569 1 Hose Assembly, LP Gas, 9/16-18 LH, 13" LP Valves Assy to LP Burner
ASSY 1021152 1 Assembly, LP Valves Includes Items 5, 18-22
18 5121 1 Y-Strainer, 1/4 NPT, 40 Mesh
19 5405-4-4 3 Adapter, Hex Pipe, -4 NPTF/-4 NPTF
20 1021140 1 Mount, LP Tee
21 1008655-02 2 Adapter, 1/4" NPT RH/ 9/16" UNF LH
22 6120 1 Valve, Medium Pressure, 1/4 NPT
23 6297SRV 1 Valve, Pilot, LP
24 300-6 4 Washer, Flat, SAE, 3/8
25 204-6-16-5 6 Nut, Lock, Stover, 3/8-16, GR5
26 23508-01 1 Bracket, LP/B3 Includes Items 27 & 28
27 114-4-20-24 2 Set Screw, SQ HD, Cup, 1/4-20 x 1.50
28 202-4-20-5 2 Nut, Hex, Jam, 1/4-20, GR5
29 1017673SRV 1 Burner, B3, LPG
30 5504-4-4 1 Pipe, Elbow Adapter, 90°, -4 NPTF--4 NPTF
31 1020156 1 Sheet, Cover, Burner
L300 and L600 Tack Distributors
Illustrated Parts List
7-33
