OPTION - Diesel Burner Group (1 of 3)
Item
No.
Part Number Qty. Description Remarks
GRP 1021531 1 Group - Diesel Burner
Not All Items Shown
1 1021936 1 Burner, Diesel, MDL SDC, 500,000 BTU
- 1021936-01 1 Igniter Assembly
- 1021936-02 1 Motor
- 1021936-03 1 Blower
2 35246 2 Fitting, Straight, -04MP/-4MS, LPG
3 70957 2 Fitting, Push-Lok, -4FJX/-4 Hose
4 801-4-BLK A/R Hose, Hydraulic, Push-Lok, Black, -4
5 204-6-16-5 6 Nit, Lock, Stover, 3/8-16, GR5
6 301-6 6 Washer, Flat, USS, 3/8
7 1021938 1 Cover, Diesel Burner
L300 and L600 Tack Distributors
Illustrated Parts List
7-35
