OPTION - Spray Bar
Item
No.
Part Number Qty. Description Remarks
OPT 1021915 1 OPTION - Spray Bar, L300
Includes Items 1-31
OPT 1021989 1 OPTION - Spray Bar, L600
Includes Items 1-30, 32
1 851939 1 Mounting Assembly, Spray Bar
2 980718 2 Mount
3 980719 2 Mount, Tack Tank, Spray Bar
4 1020164 1 Weldment, Mount, Spray Bar, Tack Tank
5 100-12-10-32-5 2 CSHH, 3/4-16 x 2.00, GR5
6 300-12 4 Washer, Flat, SAE, 3/4
7 204-12-10-5 2 Nut, Lock, Stover, 3/4-10, GR5
8 100-8-13-20-5F 2 CSHH, 1/2-13 x 1.25, GR5, FT
9 100-8-13-68-5 2 CSHH, 1/2-13 x 4.25, GR5
10 100-8-13-76-5 2 CSHH, 1/2-13 x 4.75, GR5
11 300-8 14 Washer, Flat, SAE, 1/2
12 204-8-13-5 6 Nut, Lock, Stover, 1/2-13, GR5
13 851924L 1 Arm Assembly, Spray Bar, LH
Includes Items 15-21
14 851924R 1 Arm Assembly, Spray Bar, RH
Includes Items 15-21
15 99539 2 Plug, 1" SQ HD
(1) Per Arm Assembly
ASSY 851923 6 Assembly, Spray Bar Nozzle
(3) - Per Arm Assembly
16 5605-16-16-16 6
Adapter, Female Pipe Tee, -16 NPTF/-16 NPTF/-16NPTF
(1) Per Nozzle Assembly
17 99990 6 Pipe, Bushing, 1.00MP x .500FP
(1) Per Nozzle Assembly
18 280270 6 Pipe Nipple, 1/2" NPT
(1) Per Nozzle Assembly
19 32874 6 Valve, Ball, 1/2"
(1) Per Nozzle Assembly
20 5406-8-4 6 Pipe, Bushing, Reducer, -8/-4
(1) Per Nozzle Assembly
21 280310 6 Nozzle, Tack Spray
(1) Per Nozzle Assembly
22 851931 2 Arm, Spray Bar Tow Support
23 80338 2 Clip, Clevis Pin
24 200-8-13-5 1 Nut, Hex, 1/2-13, GR5
25 851928 2 Spacer, Spray Bar Arm
26 200-10-11-5 2 Nut, Hex, 5/8-11, GR5
27 490080 2 Washer, Belleville, 5/8
28 2501-10-16 2 Adapter, Elbow, 90°, -10 JIC/-16 NPTF
29 2702-8-8-LN 1 Adapter, Bulkhead Elbow, 45°, -8 JIC/-8
30 6801-LL-8-10 NOW 1 Adapter, Elbow, 90°, Extra Long, -8 JIC/-10 O-Ring
31 1021972 1 Hose Kit, Spray Bar, Standard, L300
Not Shown, See Fig 7-10
32 1021991 1 Hose Kit, Spray Bar, Standard, L600
Not Shown, See Fig 7-10
L300 and L600 Tack Distributors
Illustrated Parts List
7-41
