OPTION - In-Cab Control (1 of 2)
Item
No.
Part Number Qty. Description Remarks
OPT 1021918 1 OPTION - In-Cab Controls, L300
Includes Items 1-9, 10A, 19A
OPT 1021992 1 OPTION - In-Cab Controls, L600
Includes Items 1-9, 10B, 19B
1 6602-12-12-12 1 Adapter, Run Tee, Swivel, -12 JIC/-12 JIC/-12 JIC
2 2702-8-8-LN 1 Adapter, Bulkhead Elbow, 45°, -8 JIC/-8
3 1013996 1 Bracket Assembly, Remote Spray Bar Valve
See Fig 7-21
4 987557 1 Cable Bracket
5 100-6-16-20-5 2 CSHH, 3/8-16 x 1.25, GR5
6 302-6 2 Washer, Lock, 3/8
7 300-6 2 Washer, Flat, SAE, 3/8
8 1019743 1 Harness, Actuator Valve Switch
Not Shown, See Section 6-Schematics
9 1020500 1 Harness, Actuator Valve Power
Not Shown, See Section 6-Schematics
10A 1019744 1 Harness, Control Switch, Actuator Valve, L300
Includes Items 9-16
10B 1019752 1 Harness, Control Switch, Actuator Valve, L600
Includes Items 9-16
11 3400DI 1 Water Tight Connector, 3/4 x 3/4
12 920238-2 1 Condulet, 3/4" Aluminum
13 900080 1 Switch, Toggle, , 3-POS, 2-POL, MOM
14 920238-4 1 Gasket, Condulet Box, 3/4"
15 920238-3 1 Cover, 3/4" Condulet
16 851441 1 Weather Boot, Toggle Switch
17 920238-5 1 Aluminum Plug, 3/4" Condulet
18 1019286 1 Decal, Oper, In-Cab, Tack Tanks
19A 1021985 1 Hose Kit, In-Cab Control, Spray Bar, L300
Not Shown, See Fig 7-21
19B 1021996 1 Hose Kit, In-Cab Control, Spray Bar, L600
Not Shown, See Fig 7-21
L300 and L600 Tack Distributors
Illustrated Parts List
7-43
