OPTION - In-Cab Control (2 of 2)
Item
No.
Part Number Qty. Description Remarks
OPT 1021918 1 OPTION - In-Cab Controls, L300
Includes Items 1-28,29A
OPT 1021992 1 OPTION - In-Cab Controls, L600
Includes Items 1-28,29B
1 1013996 1 Bracket Assembly, Remote Spray Bar Valve
2 980411 1 Plate, Tack Tank Hose Cover
3 23252 1 Actuator, Emulsion/Throttle
4 987231 1 Adjuster, Electric Screw Bottom
5 987232 1 Adjuster, Electric Screw Top
6 987182 1 Plate, Remote Spray Bar
7 100-4-20-20-5 2 CSHH, 1/4-20 x 1.25, GR5
8 204-4-20-5 2 Nut, Lock, Stover, 1/4-20, GR5
9 200-6-16-5 2 Nut, Hex, 3/8-16, GR5
10 302-6 2 Washer, Lock, 3/8
11 300-6 7 Washer, Flat, SAE, 3/8
12 204-6-16-5 3 Nut, Lock, Stover, 3/8-16, GR5
13 910080 1 Valve, Selector
14 2404-8-8 2 Adapter, Connector, -8 JIC/-8 NPTF
15 2501-8-8 1 Adapter, Elbow, 90°, -8 JIC/-8 NPTF
16 987179 2 Bracket, Remote Spray Bar
17 900020 2 Switch, Neutral Safety
18 122-#6-32-20F 4 PHMS, Cross, #6-32 x 1.25, FT
19 215-#6-32 4 Nut, Hex, Mach, LW, #6-32
20 100-5-18-16-5F 2 CSHH, 5/16-18 x 1.00, GR5, FT
21 302-5 2 Washer, Lock, 5/16
22 300-5 6 Washer, Flat, SAE, 5/16
23 100-8-13-64-5 2 CSHH, 1/2-13 x 4.00, GR5
24 300-8 4 Washer, Flat, SAE, 1/2
25 204-8-13-5 2 Nut, Lock, Stover, 1/2-13, GR5
26 100-5-18-28-5 2 CSHH, 5/16-18 x .75, GR5
27 204-5-18-5 2 Nut, Lock, Stover, 5/16-18, GR5
28 100-6-16-16-5F 2 CSHH, 3/8-16 x 1.00, GR5, FT
29A 1021985 Hose Kit, In-Cab Control, Spray Bar, L300
Includes Items 30-32A
29B 1021996 Hose Kit, In-Cab Control, Spray Bar, L600
Includes Items 30-31,32B
30 F387TCL706081008-20 1 Hose Assembly, 20", Control Valve to Spray Bar Tee
31 F387TCL706080808-46 2 Hose Assembly, 46", Bulkhead to Control Valve
32A F387TC0606081208-75 1 Hose Assembly, 75", Asphalt Valve Tee to Bulkhead
32B F387TC0606080808-125 1 Hose Assembly, 125", Asphalt Valve Tee to Bulkhead
