LeeBoy L600 - Page 148

Hose
No.
Qty. Part Number Description
GRP 1 1021940 Main Hose Kit
FROM TO
1 1 F387TC0606121212-43 3-Way Valve Pump
2 1 F387TC0606080808-35 Tee Selector Valve Port D
3 1 F387TC0606080808-67 Pump RV Selector Valve Port C
4 1 R801NRNR000008-19.25 Flush Tank 1/2” Ball Valve
Hose
No.
Qty. Part Number Description
GRP 1 1021972 OPTION - Spray Bar Hose Kit, L300
FROM TO
1 1 F387TC0606080808-96 Selector Valve Port A Bulkhead Fitting
2 1 F387TC0606081008-48 Bulkhead Fitting Spray Bar Tee
3 1 F387TC0606101008-45 Spray Bar Tee Spray Bar - Left
4 1 F387TC0606101008-46 Spray Bar Tee Spray Bar - Right
Hose
No.
Qty. Part Number Description
GRP 1 1021991 OPTION - Spray Bar Hose Kit, L600
FROM TO
1 1 F387TC0606080808-180 Selector Valve Port A Bulkhead Fitting
2 1 F387TC0606081008-48 Bulkhead Fitting Spray Bar Tee
3 1 F387TC0606101008-45 Spray Bar Tee Spray Bar - Left
4 1 F387TC0606101008-46 Spray Bar Tee Spray Bar - Right
Hose
No.
Qty. Part Number Description
GRP 1 - LP Burner Hose Kit
FROM TO
1 1 1021572 LP Regulator LP Valve Assy
2 1 1021571 LP Valve Assy Burner Wand
3 1 1021569 LP Valve Assy LP Burner
Hose
No.
Qty. Part Number Description
GRP 1 1021966 Spray Wand Hose Kit, L300
FROM TO
1 1 F387TC0606080808-84 Selector Valve Port B Bulkhead Fitting
2 1 F387TC0606080808-31.25 Bulkhead Fitting Hose Reel
Hose
No.
Qty. Part Number Description
GRP 1 1021967 Spray Wand Hose Kit, L600
FROM TO
1 1 F387TC0606080808-144 Selector Valve Port B Bulkhead Fitting
2 1 F387TC0606080808-35 Bulkhead Fitting Hose Reel
Hose Kits
L300 and L600 Tack Distributors7-48
Hydraulic Hose Index
