Description Part No.
Item
No.
Figure
No.
Brake Assembly 5200R 340060R 16R 7-4
Brake Assembly 5200R 340060R 16R 7-5
Brake Drum Assembly, 5200# 317030 4 7-4
Brake Drum Assembly, 5200# 317030 4 7-5
Brake Shoe Kit 12 X 2 340070 17 7-4
Brake Shoe Kit 12 X 2 340070 17 7-5
Bumper 410070 23 7-12
Bumper 410070 23 7-13
Burner, B3, LPG 1017673SRV 29 7-15
Burner, Diesel, MDL SDC, 500,000 BTU 1021936 1 7-16
Burner, Wand Assembly 1008652SRV 12 7-15
Bushing, 1" MNPT x 1/2" FNPT 1009925 5 7-8
Bushing, Hex Head, 1/2" x 1/4" 280320 9 7-11
-C-
Cable 1019923 22 7-12
Cable 1019923 22 7-13
Cable Bracket 987557 4 7-20
Cable, Battery, (-) Eye/Eye, 4 AWG, 14" 1021461 34 7-12
Cable, Battery, (-) Eye/Eye, 4 AWG, 14" 1021461 34 7-13
Cable, Battery, (+) Eye/Eye, 4 AWG, 16" 1021462 35 7-12
Cable, Battery, (+) Eye/Eye, 4 AWG, 26" 1021484 35 7-13
Cap, Fuel Lockable 140030FL 2 7-6
Cap, Fuel Lockable 140030FL 2 7-17
Chain Connector 1009317-00-07 5 7-1
Clamp, Hose, #72 (4") 851437 4 7-12
Clamp, Hose, #72 (4") 851437 4 7-13
Clamp, Insulated Band, 1.25" ID 34798 13 7-8
Clamp, Insulated Band, 3/8" 770-1154 2 7-18
Clamp, Loop, .938 OD, NPRN Cover (1) Not Shown 34797 15 7-17
Clamp, Mufer, 5" 38834 3 7-3
Clip, Clevis Pin 80338 23 7-19
Collar, Shaft, Split, .50 ID x 1.12 OD 8119-2 3 7-2
Collar, Shaft, Split, .50 ID x 1.12 OD 8119-2 3 7-2
Condulet, 3/4" Aluminum 920238-2 12 7-20
Cone, Roller Bearing 610210 7 7-4
Cone, Roller Bearing 610240 9 7-4
Cone, Roller Bearing 610210 7 7-5
Cone, Roller Bearing 610240 9 7-5
Contents Gauge - Front See Fig 7-2 36 7-1
Contents Gauge - Rear See Fig 7-2 35 7-1
Coupler, 2" Ball, Adjustable 510200A 9 7-1
Coupling, Half, L-Type Jaw, 1/2" Bore w/Keyway 280050 8 7-12
Coupling, Half, L-Type Jaw, 1/2" Bore w/Keyway 280050 8 7-13
Coupling, Half, L-Type Jaw, 3/4" Bore w/Keyway 150150A 6 7-12
Coupling, Half, L-Type Jaw, 3/4" Bore w/Keyway 150150A 6 7-13
L300 and L600 Tack Distributors7-54
Alphabetical Parts Index
