Table 2-11. L600 System Capacity Specications
ITEM
SPECIFICATION
Standard Honda Gas Engine Hatz Diesel Engine OPTION
Engine Oil
1 qt (.94 L)
1.16 Qts (1.1 L)
Fuel
1 gal (3.8 L) 1 gal (3.8 L)
Table 2-12. L600 Tack Tank Specications
ITEM SPECIFICATION
Asphalt Pump
Custom-Designed .761 CIR (cubic inches per revolution)
7 GPM (gallons per minute)
Heat System Two (2) 54,000 BTU Propane Burners
Temperature Gauge 50° - 300° F (10° - 150° C)
Asphalt Tank
Elliptical shape for more efcient heating, circulating and cleaning. Manhole
top opening (20 inches; 50.8 cm). Contents gauge on front and rear.
Multi-pass V-ue tubes at bottom of tank. An insulated tank option is also
available.
Asphalt Tank Dimensions
Length: 8.1 ft (2.5 m)
Width: 4 ft 6 in (1.8 m)
Height: 3 ft (.9 m)
Asphalt Tank Capacity 600 Gallons (2271.2 L)
Hose and Reel 40 ft. (12.2 m) heavy-duty hose with reel.
Spray Wand 6-ft. (1.8 m) Wand (with On/Off valve and removable spray tip).
Pintle Eye Hitch
Forged 3” ID x 1-3/8” Tow Ring. Rated 25,000 lbs.
Brakes Electric
Table 2-13. L600 Optional Equipment Specications
ITEM SPECIFICATION
Spray Bar
8-ft. Spray Bar: Folds to a lockable position. Separate cut-off valves to
control each of six (6) spray nozzles.
Overnight Heater
120-volt, 1500-watt immersion element.
In-Cab Controls Allows spray bar operation from the convenience of vehicle cab.
Hatz Diesel Engine
Hatz 1B30, 5 HP (3.7 kW), Direct injection, 4-stroke.
One 300,000 BTU diesel burner with Outre, 7-gallon diesel fuel tank and
AUTO ignition.
Diesel Burner Package
One 300,000 BTU diesel burner with Outre, 7-gallon diesel fuel tank and
AUTO ignition.
22
L300 and L600 Tack Distributors
2-7
Information and Specications
