Wiring of the standard device
Wiring of the feedback system
Important notes
5
5.8
5.8.1

5.8−1
EDSVF9383V EN 7.1−04/2012
5.8 Wiring of the feedback system
5.8.1 Important notes
Æ’ An incremental encoder can be connected to input X8 or input X9:
– Incremental encoders with TTL level are connected to X8.
– Incremental encoders with HTL level are connected to X9.
Æ’ The incremental encoder signal can be output for slave drives at the
digital frequency output X10.
 Note!
Æ’ We recommend to use Lenze system cables for wiring.
ƒ For self−made cables only use cables with shielded cores
twisted in pairs.
Installation material required from the scope of supply:
Description Use Quantity
Protective cover Protection for unused Sub−D connections 4
